What types of cable connectors are there

Cable lug is a very widely used special equipment, and cable lugs also have many types, for the cable lug type is determined by many factors, according to the cable lug installation, performance, structure, and use can be divided into different types. Generally in the shape of the structure can be divided into round and rectangular, according to the operating frequency can be divided into low-frequency and high-frequency, we can also be divided in its versatility and technical standards can be divided into low-frequency circular connectors, printed circuit cable lugs, fiber optic connectors, RF connectors, and rectangular cable lugs. So according to the technical standards, do you know how the cable lug is specifically divided?

Here is the content list:

•Type designation of cable connectors

•Type designation of cable lugs

Type designation of cable lugs

The type designation of cable lugs is the basis for customer procurement and manufacturer organization of production. In the cable lug industry at home and abroad, the product model naming has two ideas: one is to use the letter code plus the number approach and strive to reflect the main structural characteristics of the product in the model naming. The advantage of this approach is easy to identify, but the arrangement is too long and too complex, with the miniaturization of the cable connector, to bring a lot of difficulties in printing. This approach is still popular in China, and in some industry standards and even national standards to make provisions, such as SJ2298-83 (printed circuit connectors), SJ2297-83 (rectangular connectors), SJ2459-84 (ribbon cable connectors), GB9538-88 (ribbon cable connectors), etc... Due to the increasing diversity of cable connector structures, it is increasingly difficult in practice to use a naming rule to cover a particular type of cable lug. Another way of thinking is to use a combination of Arabic numerals. This approach has the advantage of simplicity, ease of computer management, and printing of logos for smaller products. The major international manufacturers of cable lug are currently using this approach. It can be expected that the development of nomenclature by each manufacturer to reflect their characteristics will gradually replace the industry-wide unified approach to naming rules under a planned economy.

The specific classification of connectors

Cable lug product type classification although some confusion, but from a technical point of view, the main classification of cable lugs product categories are according to the shape of the structure: round and rectangular (cross-section), according to the working frequency: low frequency and high frequency (to 3MHz as the boundary). As for other uses, installation methods, special structures, special performance, etc. can also be divided into many different types, and often appear in publications and manufacturers' promotional materials, but generally only to highlight a particular feature and use, the basic classification is still not beyond the above principles of classification. Taking into account the technical development of connectors and the actual situation, from its generality and the relevant technical standards, cable lugs can be divided into the following categories (subcategories): low-frequency circular cable lugs; rectangular cable lugs; printed circuit cable lugs; radio frequency cable lugs; optical fiber cable lugs.
